Customized Solutions
With our highly qualified development team and in-house production we reach maximum innovation and flexibility.
We are committed to meet our customers' requirements in regard to the quality of our products. The customer's benefit is our top priority. Satisfied customers are the confirmation of a job well done.
Intensive consulting during concept and specification development
50 years of expertise
cooperation partners for different sectors (from automotive to cutting industry)
The complete expert knowledge in-house
power and control electronics
field bus systems
FPGA and microcontroller programming
Windows® or Linux™ programming
circuit simulation and circuit layout
thermal simulation
mechanical 3D construction
EMC
assistance for certification projects (UL, NRTL, CSA, TÜV)
Flexibility of an independent, middle-size company
short decision-making paths
speedy implementation
made in Germany
Qualified support for product launch
initial operation of the complete system
Extensive testing
EMC tests
power tests
climate tests
Servo Amplifiers for Customized Solutions
In many cases modern machines and applications are very specialized and therefore the use of standard drive components would be a compromise. Under such circumstances only a customized solution will fully meet the special requirements.
The list of possibilities begins with hardware adjustments, such as special housings or interfaces and also offers completely new defined devices and functions. We are open for your ideas.
Experienced in high-volume production of customized drive systems, SIEB & MEYER is the right partner for your projects. From project planning to serial production we are at your disposal.
Take advantage of our know how in established standard components as a basis for your project.
Case Studies
Experienced in high-volume production of customized drive systems, SIEB & MEYER is the right partner for your projects. From project planning to serial production we are at your disposal.
High-dynamic Servo Amplifier for Tightening Systems in the Automotive Industry
On behalf of a client SIEB & MEYER has developed a servo amplifier for global use. The device comes with three power ranges and two installation concepts.
Client requirements:
The client planned a compact tightening (nutrunner) control using his own control card and a servo amplifier purchased in addition. The servo amplifier should work as central component and supply the control card. Two different installation concepts of the servo amplifier were demanded – one with device housing for a switch cabinet and another as board solution.
Since the client supplies the global market, the required system must support the worldwide varying mains conditions. This requirement applies especially for the US market which is strategically important for the client.
The servo amplifier should operate servo motors with speeds up to 40,000 rpm. Due to the application the motor as well as the driving servo amplifier require a high overload capacity – the construction volume, however, should remain quite small. The client uses motors with various power and voltage data and wished for a servo amplifier that is optimally adapted to these conditions.
The process data – such as the torque and the rotation angle – should be transmitted via the motor cable. For this purpose the servo amplifier should provide specific sensor interfaces.
The customized solution by SIEB & MEYER:
SIEB & MEYER assisted the client from the design phase to serial production. In cooperation the partners developed a customized system solution that, for example, provides the interface for the transducer evaluation on the servo amplifier and not on the control card for connection-related reasons.
The customized development is based on the well-proven technology of the servo amplifier series SD1. There are six different device variants based on only one PCB layout with different equipment variants, which makes the greatest number of common parts possible.
Together the companies developed the hardware and software interface for the control card enabling a flexible access to the servo amplifier. This way the client can implement his application software easily by himself.
In order to comply with the special requirements of the US market, the device development included the UL certification.
The most important details in short:
three power ranges with two different installation concepts each
supply voltage: 1 x 230 or 3 x 230 VAC, 50/60 Hz
max. rated current/peak current (5 s): 10/56 Arms
hardware and software interface to the client's control card
interfaces for torque sensors (transducer)
UL certified, NRTL approved
High-dynamic Two-channel Servo Amplifiers for Tightening Systems in the Automotive Industry
On behalf of a client SIEB & MEYER has developed a double-axis drive amplifier to be used as central component in a two-channel tightening (nutrunner) system.
Client requirements:
The client planned a compact two-channel tightening system using his own control card and a double-axis servo amplifier purchased in addition. The servo amplifier should work as central component with integrated control technology.
In addition, the client required a device that makes two different installation concepts possible – a switch cabinet version with IP20 housing and a board solution to be installed in the client's device housing.
The servo amplifier should operate servo motors with speeds up to 40,000 rpm. Due to the application the motor as well as the driving servo amplifier require a high overload capacity – the construction volume, however, should remain quite small.
The client uses motors with various power and voltage data and wished for a servo amplifier that is optimally adapted to these conditions. Beside high availability, the devices must provide scalability and excellent quality of current feed.
The customized solution by SIEB & MEYER:
SIEB & MEYER assisted the client from the design phase to serial production. In cooperation the partners developed a customized system solution. The customized development is based on the well-proven technology of the servo amplifier series SD2 that was especially designed for multi-axis applications.
There are six different device variants based on the output stages of the series devices. All six cards use the same PCB layout but have different equipment variants, which makes the greatest number of common parts possible.
The drive amplifier and the measurement and control group are accommodated in a common, compact housing – this saves installation space, makes external wiring redundant and ensures quick and trouble-free exchange of the unit when service is required.
Together the companies developed the hardware and software interface for the control card enabling a flexible access to all process-related objects of both tightening channels. This way the client can implement his application software easily by himself.
The most important details in short:
customized double-axis servo amplifier
three power ranges and two different installation concepts
input: 3 x 230 VAC and 4 x 400 VAC, 50/60 Hz
max. rated current/peak current (5 s): 2 x 7/42 Arms
hardware and software interface to the client's control card
